PROBE HOLDERS/ TRIAXIAL ISOLATION

Part Number

TRX-L-60-#

Title

PROBE HOLDERS/ TRIAXIAL ISOLATION

Applications

CV/IV Measurements & Failure Analysis
Low Current Analysis
Manual Analytical Probing
MEMS Probing

Description

VERY LOW LEAKAGE, ISOLATED 2fA TRIAX PROBE HOLDER

TRIAXIAL PROBE TIP HOLDER WITH ISOLATION AND SCREW -LOCK, SPECIFICALLY DESIGNED FOR VERY LOW NOISE MEASUREMENTS.

Documents
Technical Specifications
LEAKAGE CURRENT
>= 2fA @ AMBIENT
MATERIAL
BRASS
LENGTH
170mm
CABLE LENGTH
152.4cm
CONNECTION
TRIAX
WIRE
TRIAX
TEMPERATURE
-65°C TO +200°C
TIP MOUNT
SCREW-LOCK
